SMP1322-075LF SOT-323 SKYWORKS original stock
explain
The SMP1322 series plastic packaging, with a surface mounted PIN diode, is designed for high-capacity switching applications from 10 MHz to 10 GHz and above. The ultra-low resistance of these diodes (maximum 1.5 Ω at 1 mA, typical 0.5 Ω at 10 mA) makes the SMP1322 series particularly suitable for low loss PIN diode switches in battery operated circuits.
The SMP1322 series comes in various plastic packaging and configurations, including SOT-23, SC-70, Small Footprint SC-79, and Small SOD-882.
characteristic
Resistance: 0.5 Ω typical value @ 10 mA
Capacitance: maximum 1 pF at 30 V
Packaging with rated MSL1260 according to JEDEC J-STD-020
application program
The SMP1322 series plastic packaging, with a surface mounted PIN diode, is designed for high-capacity switching applications from 10 MHz to 10 GHz and above. The ultra-low resistance of these diodes (maximum 1.5 Ω at 1 mA, typical 0.5 Ω at 10 mA) makes the SMP1322 series particularly suitable for low loss PIN diode switches in battery operated circuits.
The SMP1322 series comes in various plastic packaging and configurations, including SOT-23, SC-70, Small Footprint SC-79, and Small SOD-882.
characteristic
Resistance: 0.5 Ω typical value @ 10 mA
Capacitance: maximum 1 pF at 30 V
Packaging with rated MSL1260 according to JEDEC J-STD-020
application program
High performance wireless switch applications
