RT9193-33GB Linear Voltage Stabilizer (LDO) RICHTEK Original Stock

explain
RT9193 is designed for portable RF and wireless applications with demanding performance and space requirements. The performance of RT9193 has been optimized for battery powered systems to provide ultra-low noise and low quiescent current. A noise bypass pin can be used to further reduce output noise. The grounding current of the regulator only slightly increased, further extending the battery life.

RT9193 also works with low ESR ceramic capacitors, reducing the board space required for power applications, which is crucial in handheld wireless devices. The consumption of RT9193 in shutdown mode is less than 0.01 μ A. And the fast opening time is less than 50 μ S. Other features include ultra-low dropout voltage, high output accuracy, current limiting protection, and high ripple suppression ratio. SC-70-5, SOT-23-5, TSOT-23-5, WDFN-6L 2x2, and MSOP-8 software packages are available.

Features

Ultra Low Noise for RF Application

Ultra Fast Response in Line/Load Transient

Quick Start-Up (Typically 50μs)

<0.01μA Standby Current When Shutdown

Low Dropout : 220mV @ 300mA

Wide Operating Voltage Ranges : 2.5V to 5.5V

TTL-Logic-Controlled Shutdown Input

Low Temperature Coefficient

Current Limiting Protection

Thermal Shutdown Protection

Only 1μF Output Capacitor Required for Stability

High Power Supply Rejection Ratio

Custom Voltage Available

RoHS Compliant and 100% Lead (Pb)-Free

Applications

CDMA/GSM Cellular Handsets

Battery-Powered Equipment

Laptop, Palmtops, Notebook Computers

Hand-Held Instruments

PCMCIA Cards

Portable Information Appliances
