LV25-P current sensor LEM original stock
Features
● Closed loop (compensated)
current transducer using the Hall
effect
● Insulating plastic case recognized
according to UL 94-V0.
Principle of use
● For voltage measurements,
a current proportional to the
measured voltage must be
passed through an external
resistor R1 which is selected by
the user and installed in series
with the primary circuit of the
transducer.
Advantages
● Excellent accuracy
● Very good linearity
● Low thermal drift
● Low response time
● High bandwidth
● High immunity to external
interference
● Low disturbance in common
mode.
Applications
● AC variable speed drives and
servo motor drives
● Static converters for DC motor
drives
● Battery supplied applications
● Uninterruptible Power Supplies
(UPS)
● Power supplies for welding
applications.
Application domain
● Industrial.
