JW5026SOTB # TRPBF Package: SOT-23-6 DC-DC power chip Joulwatt original stock

describe
     JW5026 is a current mode single-chip buck switching regulator. The input range of JW5026 is 4.7V~40V, providing two integrated channels of continuous output current. The internal synchronous power switch provides high efficiency without using external Schottky diodes. Under light load, the regulator operates in continuous conduction mode to maintain low output ripple. Current mode control provides tight load transient response and cycle by cycle current limitation.
     JW5026 ensures the robustness of input under short-circuit protection, thermal protection, current loss protection, and voltage locking.
     JW5026 has a 6-pin SOT23-6 package, which provides a compact solution with minimal external components.

FEATURES

Battery Powered Systems
