522070660 FFC/FPC connector MOLEX agent shipment
522070660
Specification information:
Operating temperature range: -30C to 85C
Contact plating: Gold Over Nickel
Maximum contact resistance: 20 Mohm
Rated current (maximum): 1/Contact A
Shell material: Nylon 46
Packaging: Tape and Reel
Type: FPC Connector
Contact lines: 1
Contact material: Phosphor Bronze
Contact points: 6 POS
Shell color: Natural
Product length (mm): 13.9 mm
Product thickness (mm): 8.9 mm
Product height (mm): 2.7 mm
Maximum rated voltage: 30V
Termination: Solder
Contact type: SKT
Specification information:
Operating temperature range: -30C to 85C
Contact plating: Gold Over Nickel
Maximum contact resistance: 20 Mohm
Rated current (maximum): 1/Contact A
Shell material: Nylon 46
Installation Style: Surface Mount
Style: Right AnglePackaging: Tape and Reel
Type: FPC Connector
Contact lines: 1
Contact material: Phosphor Bronze
Contact points: 6 POS
Shell color: Natural
Product length (mm): 13.9 mm
Product thickness (mm): 8.9 mm
Product height (mm): 2.7 mm
Maximum rated voltage: 30V
Termination: Solder
Contact type: SKT
Spacing (mm): 1 mm
