522710679 FFC/FPC connector MOLEX in stock
522710679
Specification information:
Type: FPC Connector
Spacing: 1 mm
Contact points: 6
Number of rows: 1
Style: Right Angle
Installation: Surface Mount
Standard Packaging: Tape & Reel
Unit Pack: 1000
Minimum order quantity: 6000
Operating temperature range: -40C to 85C
Contact plating: Tin Bismuth
Rated current (maximum): 0.5/Contact A
Shell material: Nylon 4/6
Installation Style: Surface Mount
Packaging: Tape and Reel
Contact lines: 1
Contact material: Phosphor Bronze
Shell color: Natural
Product thickness (mm): 6.7 mm
Product height (mm): 3 mm
Maximum rated voltage: 50VDC/50VAC
Termination: Solder
Contact type: SKT
Specification information:
Type: FPC Connector
Spacing: 1 mm
Contact points: 6
Number of rows: 1
Style: Right Angle
Installation: Surface Mount
Standard Packaging: Tape & Reel
Unit Pack: 1000
Minimum order quantity: 6000
Operating temperature range: -40C to 85C
Contact plating: Tin Bismuth
Rated current (maximum): 0.5/Contact A
Shell material: Nylon 4/6
Installation Style: Surface Mount
Packaging: Tape and Reel
Contact lines: 1
Contact material: Phosphor Bronze
Shell color: Natural
Product thickness (mm): 6.7 mm
Product height (mm): 3 mm
Maximum rated voltage: 50VDC/50VAC
Termination: Solder
Contact type: SKT
Spacing (mm): 1 mm
