670688000 USB connector MOLEX in stock
670688000
Specification information:
Packaging: Plug-ins
Number of pins: 4
Number of circuits: 4
Contact points: 4
Rows: 2
Insulation resistance: 1.00 G_
Polarity: Female
Pin spacing: 2.50 mm
Rated current: 1.50 A
Shell material: Thermoplastic
Flammability rating: UL 94 V-0
Contact material: Phosphor Bronze
Color: Black
Shell color: Black
Halogen-free state: Not Low Halogen
Contact plating: Gold Flash, Gold
Direction: Right Angle
Length: 17.0 mm
Width: 12.0 mm
Height: 11.0 mm
Installation method: Solder, Through Hole, PCB
Packaging method: Tray
REACH SVHC Standard: No SVHC
Lead standard: Lead Free
RoHS standard: Compliant
Specification information:
Packaging: Plug-ins
Number of pins: 4
Number of circuits: 4
Contact points: 4
Rows: 2
Insulation resistance: 1.00 G_
Polarity: Female
Pin spacing: 2.50 mm
Rated current: 1.50 A
Shell material: Thermoplastic
Flammability rating: UL 94 V-0
Contact material: Phosphor Bronze
Color: Black
Shell color: Black
Halogen-free state: Not Low Halogen
Contact plating: Gold Flash, Gold
Direction: Right Angle
Length: 17.0 mm
Width: 12.0 mm
Height: 11.0 mm
Installation method: Solder, Through Hole, PCB
Packaging method: Tray
REACH SVHC Standard: No SVHC
Lead standard: Lead Free
RoHS standard: Compliant
Product life cycle: Active
